Agile capture.
Precise data.
The Totem NEO is the compact and flexible option within the iNuba ecosystem. Designed for centres that want to integrate advanced measurement into their usual workflow, without disrupting operations.
The Totem NEO fits where
space is valuable.
Not every centre has a dedicated booth. The NEO turns any room into a clinical measurement point — no construction, no waiting.
Clinics with moderate volume
Centres that want to integrate objective measurement without dedicating an exclusive space or modifying their current layout.
Wellness and wellbeing centres
Wellbeing spaces looking to add a data layer to personalise the client experience.
Corporate environment
Companies with health programmes that need periodic measurements for their employees in an agile, non-invasive way.
Professionals who embrace technology
The innovation that sets you apart from the rest.
Cutting-edge client experience
Every interaction with your patient, designed to be remembered.
Teams with a professional present
When a professional is guiding the patient, the NEO delivers full measurement capability without technological overload.
Three measurement systems,
one single experience.
The Totem NEO combines advanced clinical technologies in a compact format that can be installed in any space in less than a day.
3D Body Scan
Three-dimensional body model with 2K FHD resolution. Captures measurements and volumes that no tape measure can provide.
- Realistic 3D avatar 2K FHD (1920×1080)
- Millimetre precision in every measurement
- Automated futuristic experience
- Complete body parametrisation
- Perimeters, segments, areas, volumes, asymmetries...
- >200 directly measured parameters
Segmental BIA
Segmental body composition analysis: muscle mass, fat, intra- and extracellular water with 5 measurement frequencies.
Delivers more data than the competitor's premium equivalent, including key body composition values: reactance, phase angle and resistance.
With iNuba's proprietary and pioneering "3D-Mapping" technology that generates greater reliability and precision by combining the 3D avatar and volumetry with bioimpedance.
Performs 25 bioelectrical impedance (Z) measurements using 5 different frequencies (8kHz, 50kHz, 250kHz, 500kHz and 1MHz) across 5 body segments: Right Arm, Left Arm, Trunk, Right Leg and Left Leg.
- 8 electrodes on hands and feet simultaneously
- Muscle mass per body segment
- Visceral, subcutaneous and total fat
- Intracellular and extracellular water
- Phase angle as a cellular health marker
- 5 measurement frequencies (8–1000 kHz)
Infrared thermography
Integrated thermal camera that detects skin temperature asymmetries and inflammation zones, useful for clinical monitoring and prevention.
- Full-body thermogram (382×288 pixels)
- Automatic body segmentation
- 133 ROIs (Regions of interest)
- 399 directly measured parameters (Max, Mean and Min Tº per ROI)
- Advanced per-test analysis and history in iNuba Clinic
- Filtering and treatment of areas with injuries
- Automated alerts that facilitate analysis and monitoring
Construido para entrar
en cualquier centro.
Diseño, instalación, experiencia de uso y tecnología exclusiva. Todo en un dispositivo compacto y sin concesiones.
Diseño minimalista y elegante
Un dispositivo que encaja en cualquier entorno clínico sin comprometer la estética.
El Totem iNuba fue diseñado en torno a tres principios: funcionalidad y precisión al servicio de la calidad. Un dispositivo que encaja en cualquier entorno clínico sin comprometer la estética.
Plug & Play
Listo para usar desde el primer momento. Operativo en menos de 15 minutos.
Listo para usar desde el primer momento. Sin instalaciones complejas ni formación técnica extensa. Conecta, configura y empieza a medir en menos de 15 minutos.
Pantalla táctil 15"
Full HD 1920×1080. Guía interactiva al paciente sin formación previa.
Pantalla de 15" FHD para configurar el dispositivo y guiar a tus pacientes en cada prueba. Diseñada para el entorno clínico: alto brillo, tacto preciso y navegación intuitiva sin formación previa.
Único en sus capacidades
El único totem del mercado con termografía autónoma integrada. Sin equivalente.
Solo iNuba incorpora un sistema termográfico autónomo integrado en un totem de medición. Una tecnología sin equivalente en el mercado que abre nuevas dimensiones diagnósticas en cada escáner.
El NEO no es
un dispositivo aislado.
Es parte de tu sistema.
Cada medición del Totem NEO viaja automáticamente a iNuba Clinic. Sin exportar archivos, sin doble entrada de datos, sin información perdida por el camino.
El paciente sube al Totem NEO
El proceso dura 90 segundos. Sin ropa adicional, sin preparación especial, sin necesidad de un profesional técnico.
El sistema captura las tres tecnologías
Escáner corporal 3D, bioimpedancia y termografía de forma simultánea y estandarizada.
Los datos se sincronizan con iNuba Clinic
Automáticamente. El profesional ve los resultados en su panel sin ninguna acción adicional.
El paciente recibe su informe en el teléfono
Resultados comparados con la medición anterior, tendencia y recomendaciones del profesional.
How the professional views patient data
Every Totem NEO measurement arrives instantly in the clinical panel. Six specialised views to gain a deep understanding of your patient's health status.
¿NEO, PRO o BOX?
Elige según tu flujo de trabajo.
If your centre handles a high measurement volume, needs higher thermography resolution or advanced body composition analysis, PRO or BOX may be your option.
|
|
 |
|
|---|---|---|---|
| iNuba Totem NEO | iNuba Totem PRO | iNubaBox | |
| Request Demo | Learn more | Learn more | |
| General | |||
| Installed dimensions | W 80cm / H 210cm / L 200cm | W 80cm / H 210cm / L 200cm | W 194cm / H 249cm / L 266cm |
| Weight | 70 kg | 70 kg | 556 kg |
| Connectivity | Dual-band WiFi | Dual-band WiFi | WiFi + 4G/LTE |
| Total scan time | 90 sec | 90 sec | 90 sec |
| Octopolar bioimpedance | |||
| No. of frequencies | 5 | 7 | 7 |
| Configurable frequencies | No | Yes | Yes |
| Measurement duration | 30 sec | 30–50 sec | 30–50 sec |
| Thermography | |||
| Resolution | 382×288 px | 680×480 px | 680×480 px |
| Accuracy | ±2% | ±1.5% | ±1.5% |
| NETD sensitivity | 50 mK | 40 mK | 40 mK |
| 3D Reconstruction | |||
| Resolution | 2K FHD | 4K UHD | 4K UHD |
| Depth error | <1.5% | <1% | <1% |
| Configurable resolution | Fixed 2K | 2K or 4K | 2K or 4K |
| CUDA cores | 4608 | 6144 | 6144 |
| Computing power (GPU) | 8GB GPU (488 GB/s) | 12GB GPU (672 GB/s) | 12GB GPU (672 GB/s) |
| Reconstruction time | 4:00 (2K) | 2:45 (2K) · 4:10 (4K) | 2:45 (2K) · 4:10 (4K) |
Does the Totem NEO fit
your centre?
In 30 minutes we analyse your needs, your space and your workflow. Our experts will help you choose the right option.
